5436937
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
BCDH RoHS Compliant 2014 Interlocking (Side) Terminal Block Header, Male Pins, Shrouded (2 Side) 90° Right Angle 12A 300V 0.933 23.70mm
PDF
/
Inventory: 1095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2014
Series BCDH
Feature Interlocking (Side)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (2 Side)
Number of Positions 10
Color Gray
Pitch 0.197 5.00mm
Insulation Height 0.933 23.70mm
Termination Style Solder
Voltage 300V
Contact Tail Length 0.126 3.20mm
Number of Levels 2
Current 12A
Contact Mating Finish Tin
Voltage - UL 300V
Voltage - IEC 400V
Positions Per Level 5
Header Orientation 90°, Right Angle
Current - IEC 10A
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
