3045800
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
DIN Rail Terminal Blocks UPBV 4/ 1
PDF
/
Buying Options
Total Price: USD $2.17
Unit Price: USD $2.1736
≥1 USD $2.1736
≥10 USD $2.11024
≥100 USD $1.97208
≥500 USD $1.814296
≥1000 USD $1.676259
≥3000 USD $1.597394
Inventory: 228
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 6.2mm
Length 21mm
Technical
Screw Size M3
Current - IEC 32A
Wire Strip Length 9mm
Wire Gauge or Range - mm2 0.14-6mm2
Plug Wire Entry 90°
Torque - Screw 0.6-0.8 Nm (5.3-7.1 Lb-In)
Voltage - IEC 800V
Wire Gauge or Range - AWG 10-26 AWG
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 26 AWG
Current 30A
Number of Levels 1
Voltage 600V
Approval Agency CSA, UL
Termination Style Screw
Current Rating 32A
Insulation Height 1.909 48.50mm
HTS Code 8536.69.40.40
Voltage - Rated 800V
Color Gray
Type Plug, Female Sockets
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CLIPLINE COMBI UPBV
Published 2011
Packaging Bulk
Physical
Weight 6.500007g
Housing Material Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 4 Weeks
