3040504
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
DIN Rail Terminal Blocks SPDB 2.5/11
PDF
/
Buying Options
Total Price: USD $80.83
Unit Price: USD $80.831314
≥1 USD $80.831314
≥200 USD $32.252701
≥500 USD $31.174811
≥1000 USD $30.643086
Inventory: 8654
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 57.2mm
Length 32.7mm
Technical
Current - IEC 24A
Wire Strip Length 10mm
Wire Gauge or Range - mm2 0.08-4mm2
Plug Wire Entry 180°
Positions Per Level 11
Voltage - IEC 500V
Wire Gauge or Range - AWG 12-28 AWG
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 28 AWG
Current 20A
Number of Levels 1 (Mate), 2 (Input)
Voltage 300V
Termination Style Screwless - Spring Cage, Tension Clamp
Current Rating 24A
Insulation Height 1.535 39.00mm
Depth 17mm
Voltage - Rated 500V
Color Gray
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 11 (Mate), 22 (Input)
Type Plug, Female Sockets
Connector Type IDC, IDT
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series CLIPLINE COMBI SPDB
Published 2011
Packaging Bulk
Physical
Weight 56.699046g
Housing Material Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 6 Weeks
