3000653
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
COMBI RECEPTACLE CONNECTION METH
PDF
/
Buying Options
Total Price: USD $1.64
Unit Price: USD $1.635581
≥1 USD $1.635581
≥10 USD $1.542999
≥100 USD $1.455664
≥500 USD $1.373268
≥1000 USD $1.295531
Inventory: 5993
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Technical
Operating Temperature -60°C~100°C
Packaging Bulk
Published 2016
Series CLIPLINE COMBI PT
Part Status Active
ECCN Code EAR99
Type Plug, Blade Pins
Color Gray
HTS Code 8536.69.40.40
Insulation Height 1.614 41.00mm
Termination Style Screwless - Leg Spring, Push-In Spring
Number of Levels 1
Voltage - UL 300V
Wire Gauge or Range - AWG 12-26 AWG
Current - UL 20A
Voltage - IEC 500V
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.14-4mm2
Wire Strip Length 8-10mm
Current - IEC 24A
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
