2909646 image
Favorite
2909646 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Pluggable Terminal Blocks 3 Pos 5mm pitch Through Hole Header
PDF
/
Buying Options
Total Price: USD $2.52
Unit Price: USD $2.51569
≥1 USD $2.51569
≥10 USD $2.373292
≥100 USD $2.238952
≥500 USD $2.112215
≥1000 USD $1.992663
Inventory: 5211
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Width 16.5mm
Length 14.65mm
Height 14.95mm

Technical

Header Orientation 90°, Right Angle
Voltage - IEC 400V
Voltage - UL 300V
Current 16A
Number of Levels 1
Max Current Rating 12A
Voltage 300V
Termination Style Solder
Current Rating 12A
Insulation Height 0.709 18.00mm
Pitch 0.197 5.00mm
Voltage - Rated 250V
Color Black
Number of Positions 3
Type Header, Male Pins, Shrouded (2 Side)
Connector Type Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series COMBICON MSTBO
Published 2011
Packaging Bulk

Physical

Weight 4.799914kg
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Free Hanging, Through Hole

Supply Chain

Factory Lead Time 4 Weeks
