1987494
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
COMBICON PT RoHS Compliant 2011 Tin Terminal Block Plug for Unshrouded Header 14AWG 90° 10A 250V
PDF
/
Inventory: 1249
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Weight 5.700012g
Technical
Packaging Bulk
Published 2011
Series COMBICON PT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Screw
Type Plug for Unshrouded Header
Number of Positions 5
Color Black
Voltage - Rated 250V
Pitch 0.197 5.00mm
Reach Compliance Code not_compliant
Current Rating 10A
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 26 AWG
Contact Mating Finish Tin
Voltage - IEC 250V
Torque - Screw 0.4 Nm (3.5 Lb-In)
Plug Wire Entry 90°
Wire Gauge or Range - mm2 0.2-2.5mm2
Wire Strip Length 5mm
Screw Size M2.6
Compliance
RoHS Status RoHS Compliant
