1959325
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
COMBICON CCA RoHS Compliant 2003 Tin Terminal Block Header, Male Pins, Shrouded (3 Side) 90° Right Angle 10A 300V 0.339 8.61mm
PDF
/
Inventory: 1213
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP)
Weight 160.000002g
Technical
Packaging Tape & Reel (TR)
Published 2003
Series COMBICON CCA
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Male Pins, Shrouded (3 Side)
Number of Positions 7
Color Black
Number of Rows 1
Voltage - Rated 250V
Additional Feature LCP, 94V-0
HTS Code 8536.69.40.40
Pitch 0.200 5.08mm
Insulation Height 0.339 8.61mm
Current Rating 12A
Termination Style Solder
Voltage 300V
Contact Tail Length 0.102 2.60mm
Number of Levels 1
Current 10A
Contact Mating Finish Tin
Number of Decks 1
Voltage - IEC 400V
Number of Ways 7
Safety Approval UL
Header Orientation 90°, Right Angle
Current - IEC 12A per position
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
