1942510
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Phoenix Contact COMBICON FKC Series 5.08mm Pitch Pluggable Terminal Block, Plug with Spring Cage Termination, 5 Way
PDF
/
Buying Options
Total Price: USD $7.05
Unit Price: USD $7.04674
≥1 USD $7.04674
≥10 USD $6.647871
≥100 USD $6.271582
≥500 USD $5.916581
≥1000 USD $5.581682
Inventory: 9504
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Free Hanging (In-Line)
Material Polyamide, Tin
Housing Material Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2015
Series COMBICON FKC
Feature Mating Flange, Retention Latches (Non-Wire Side)
Pbfree Code yes
Part Status Active
ECCN Code EAR99
Type Plug, Female Sockets
Number of Positions 5
Color Green
Number of Rows 1
Gender Female
Voltage - Rated 630V
Additional Feature PA, UL 94V-0
Pitch 0.200 5.08mm
Insulation Height 0.591 15.00mm
Current Rating 16A
Termination Style Screwless - Leg Spring, Push-In Spring
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Number of Decks 1
Wire Gauge or Range - AWG 12-26 AWG
Voltage - IEC 320V
Number of Ways 5
Safety Approval UL
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.2-2.5mm2
Wire Strip Length 10mm
Fastening Method SPRING LOADED
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
