1924240
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal block; Header; Male Pins; (4 Side); 7 pos; 0.197"(5.00mm) pitch; 16A; 300V
PDF
/
Buying Options
Total Price: USD $2.31
Unit Price: USD $2.309958
≥1 USD $2.309958
≥10 USD $2.179203
≥100 USD $2.055854
≥500 USD $1.939492
≥1000 USD $1.829704
Inventory: 6430
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2001
Series COMBICON MSTBVA
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 7
Color Green
Number of Rows 1
Additional Feature PA, UL 94V0
HTS Code 8536.69.40.40
Pitch 0.197 5.00mm
Insulation Height 0.472 12.00mm
Termination Style Solder
Contact Tail Length 0.154 3.90mm
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Number of Decks 1
Voltage - IEC 630V
Number of Ways 7
Safety Approval UL
Header Orientation Vertical
Current - IEC 16A
Rated Voltage 250V
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
