1924172
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Connector; PCB header; 16A; 320V; 11 positions; MSTB 2 5 HC/11-GF-5 08
PDF
/
Buying Options
Total Price: USD $5.39
Unit Price: USD $5.390895
≥1 USD $5.390895
≥10 USD $5.085749
≥100 USD $4.797885
≥500 USD $4.526301
≥1000 USD $4.270093
Inventory: 1198
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 12mm
Technical
Header Orientation 90°, Right Angle
Safety Approval UL
Number of Ways 11
Voltage - IEC 400V
Number of Decks 1
Contact Mating Finish Tin
Current 16A
Number of Levels 1
Contact Tail Length 0.138 3.50mm
Voltage 300V
Termination Style Solder
Current Rating 16A
Insulation Height 0.339 8.61mm
Pitch 0.200 5.08mm
HTS Code 8536.69.40.40
Additional Feature PA, UL 94V0
Voltage - Rated 250V
Number of Rows 1
Color Green
Number of Positions 11
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating and Mounting Flange
Series COMBICON MSTB
Published 2001
Packaging Bulk
Physical
Weight 4.320014g
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
