1877915
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks MVSTBW 2 5/ 8-ST BK
PDF
/
Buying Options
Total Price: USD $7.61
Unit Price: USD $7.608144
≥1 USD $7.608144
≥10 USD $7.177495
≥100 USD $6.771219
≥500 USD $6.387948
≥1000 USD $6.026364
Inventory: 1113
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Weight 1.200205kg
Technical
Packaging Bulk
Published 2011
Series COMBICON MVSTBW
Feature Retention Latches (Non-Wire Side)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Connector Type Screw, Socket
Type Plug, Female Sockets
Number of Positions 8
Color Black
Number of Rows 1
Voltage - Rated 300V
Additional Feature PA, UL 94V-0
Pitch 0.197 5.00mm
Insulation Height 0.496 12.60mm
Current Rating 10A
Termination Style Screw - Rising Cage Clamp
Voltage 300V
Number of Levels 1
Current 15A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 28 AWG
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Voltage - IEC 630V
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways 8
Safety Approval CB; CSA; CUL; GOST; UL; VDE
Plug Wire Entry 270°
Wire Gauge or Range - mm2 0.2-2.5mm2
Wire Strip Length 7mm
Current - IEC 12A
Screw Size M3
Wire Cross Section 2.5 mm2
Dimensions
Height 26mm
Length 12.6mm
Width 40mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
