1876314
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
COMBICON MC RoHS Compliant 2011 Not Applicable Terminal Block Header, Male Pins, Shrouded (4 Side) UL94V-0 90° Right Angle 3A 300V
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.476
≥1 USD $3.476
≥10 USD $3.38096
≥100 USD $3.16008
≥500 USD $2.907256
≥1000 USD $2.852854
Inventory: 1260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Housing Material Nylon
Weight 2.299997g
Technical
Packaging Bulk
Published 2011
Series COMBICON MC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 10
Color Black
Number of Rows 1
Gender Female
Voltage - Rated 160V
HTS Code 8536.69.40.40
Pitch 0.138 3.50mm
Insulation Height 0.285 7.25mm
Current Rating 8A
Termination Style Solder
Voltage - Rated AC 250V
Number of Contacts 18
Insulation Resistance 5GOhm
Voltage 300V
Contact Tail Length 0.134 3.40mm
ELV Compliant
Number of Levels 1
Current 8A
Contact Mating Finish Tin
Contact Current Rating 3A
Number of Decks 1
Voltage - IEC 160V
Number of Ways 10
Safety Approval CB; CSA; CUL; GOST; UL; VDE
Header Orientation 90°, Right Angle
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
