1861798
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 9 Pos 3.81mm pitch Through Hole Header
PDF
/
Buying Options
Total Price: USD $11.71
Unit Price: USD $11.709755
≥1 USD $11.709755
≥200 USD $4.672611
≥500 USD $4.516376
≥1000 USD $4.438915
Inventory: 920
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 6.380003g
Technical
Packaging Bulk
Published 2011
Series COMBICON MCO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (2 Side)
Number of Positions 9
Color Green
Number of Rows 1
Voltage - Rated 125V
Pitch 0.150 3.81mm
Depth 12mm
Insulation Height 1.405 35.68mm
Current Rating 8A
Termination Style Solder
Voltage 300V
Number of Levels 1
Current 8A
Contact Mating Finish Tin
Number of Decks 1
Voltage - IEC 200V
Number of Ways 9
Safety Approval UL
Header Orientation 90°, Right Angle, Vertical
Dimensions
Length 12mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
