1861691
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 7 Pos 3.81mm pitch Through Hole Header
PDF
/
Inventory: 1166
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Header Orientation 90°, Right Angle, Vertical
Safety Approval UL
Number of Ways 7
Voltage - IEC 200V
Number of Decks 1
Contact Mating Finish Tin
Current 8A
Number of Levels 1
Voltage 300V
Termination Style Solder
Current Rating 8A
Insulation Height 1.105 28.06mm
Pitch 0.150 3.81mm
HTS Code 8536.69.40.40
Additional Feature PA/PBT, 94V-0
Voltage - Rated 125V
Number of Rows 1
Color Green
Number of Positions 7
Type Header, Male Pins, Shrouded (2 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON MCO
Published 2011
Packaging Bulk
Physical
Weight 4.359987g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 7 Weeks
