1847916
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Socket enclosure - cable GMVSTBR Total number of pins 5 Phoenix Contact 1847916 Contact spacing: 7.62 mm 50 pc(s)
PDF
/
Inventory: 7941
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Plating Tin
Mounting Type Free Hanging (In-Line)
Housing Material Plastic
Technical
Packaging Bulk
Published 2015
Series COMBICON GMVSTBR
Feature Mating Flange, Retention Latches (Wire Side)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Socket
Type Plug, Female Sockets
Number of Positions 5
Color Green
Number of Rows 1
Additional Feature PA, 94V-0
Pitch 0.300 7.62mm
Current Rating 12A
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Voltage - UL 300V
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Current - UL 15A
Voltage - IEC 1kV
Number of Ways 5
Safety Approval UL
Plug Wire Entry 90°
Wire Gauge or Range - mm2 0.2-2.5mm2
Dimensions
Height 26mm
Length 12.6mm
Width 48.54mm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
