1847495
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 5 Pos 5.08mm pitch Through Hole Header
PDF
/
Buying Options
Total Price: USD $3.46
Unit Price: USD $3.45919
≥1 USD $3.45919
≥10 USD $3.26339
≥100 USD $3.078664
≥500 USD $2.904403
≥1000 USD $2.740004
Inventory: 2413
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Length 5mm
Technical
Header Orientation 90°, Right Angle
Safety Approval UL
Number of Ways 5
Voltage - IEC 400V
Number of Decks 1
Contact Mating Finish Tin
Current 8A
Number of Levels 1
Contact Tail Length 0.138 3.50mm
Voltage 300V
Termination Style Solder
Current Rating 8A
Insulation Height 0.285 7.25mm
Depth 4mm
Pitch 0.200 5.08mm
Additional Feature PBT, UL 94V-0
Voltage - Rated 250V
Number of Rows 1
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 5
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating and Mounting Flange
Series COMBICON MC
Published 2011
Packaging Bulk
Physical
Weight 122.999991g
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 5 Weeks
