1845248
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pin enclosure - PCB PC Total number of pins 7 Phoenix Contact 1845248 Contact spacing: 7.62 mm 50 pc(s)
PDF
/
Inventory: 1232
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA), Nylon
Weight 749.788188g
Technical
Packaging Bulk
Published 2011
Series COMBICON PC
Feature Retention Latches (Non-Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
ECCN Code EAR99
Connector Type Plug, Screw
Type Plug, Female Sockets
Number of Positions 7
Color Green
Voltage - Rated 400V
HTS Code 8536.69.40.40
Pitch 0.300 7.62mm
Insulation Height 0.713 18.10mm
Reach Compliance Code not_compliant
Current Rating 20A
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 10 AWG
Wire Gauge or Range - AWG 10-30 AWG
Voltage - IEC 630V
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.2-4mm2
Wire Strip Length 7mm
Screw Size M3
Dimensions
Height 30.7mm
Length 18.1mm
Width 53.32mm
Compliance
Material Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
