1830867
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Phoenix Contact IMCV Series, 3.5mm Pitch 2 Way Base Strip, Solder Termination, 8A
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.091622
≥1 USD $2.091622
≥10 USD $1.973234
≥100 USD $1.861544
≥500 USD $1.756164
≥1000 USD $1.656759
Inventory: 1110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP)
Technical
Packaging Bulk
Published 2015
Series COMBICON IMC
Feature Locking Ramp
Pbfree Code yes
Number of Positions Per Level 2
Header Orientation Vertical
Voltage - UL 300V
Contact Mating Finish Tin
Current 8A
Number of Levels 1
Voltage 300V
Termination Style Solder
Current Rating 8A
Insulation Height 0.569 14.45mm
Pitch 0.138 3.50mm
Voltage - Rated 320V
Color Black
Type Plug, Male Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
