1821122
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
MICRO-COMBICON FMC RoHS Compliant 2015 Gold Terminal Block Plug, Female Sockets 26AWG 180° 6A 150V
PDF
/
Buying Options
Total Price: USD $4.99
Unit Price: USD $4.9896
≥1 USD $4.9896
Inventory: 260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP)
Technical
Packaging Bulk
Published 2015
Series MICRO-COMBICON FMC
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
Type Plug, Female Sockets
Number of Positions 5
Color Black
Pitch 0.100 2.54mm
Insulation Height 0.213 5.40mm
Termination Style Screwless - Leg Spring, Push-In Spring
Voltage 150V
Number of Levels 1
Current 6A
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 20 AWG
Contact Mating Finish Gold
Wire Gauge or Range - AWG 20-26 AWG
Voltage - IEC 160V
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.14-0.5mm2
Wire Strip Length 7mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
