1810764
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK HDR 7POS 90DEG 2.5MM
PDF
/
Buying Options
Total Price: USD $1.9
Unit Price: USD $1.903269
≥1 USD $1.903269
≥10 USD $1.795535
≥100 USD $1.693902
≥500 USD $1.598015
≥1000 USD $1.507566
Inventory: 1147
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Number of Positions Per Level 7
Current - IEC 6A
Header Orientation 90°, Right Angle
Voltage - UL 150V
Contact Mating Finish Tin
Current 5A
Number of Levels 1
Voltage 150V
Termination Style Solder
Current Rating 6A
Insulation Height 0.197 5.00mm
Pitch 0.098 2.50mm
Voltage - Rated 160V
Color Black
Type Header, Female Sockets
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Solder Retention
Series COMBICON PTSM
Published 2014
Packaging Tape & Reel (TR)
Physical
Housing Material Liquid Crystal Polymer (LCP)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
