RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description TERM BLOCK HDR 5POS VERT 5.08MM
PDF
/
Inventory: 1088
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Positions Per Level 5
Current - IEC 12A
Header Orientation Vertical
Voltage - IEC 630V
Contact Mating Finish Tin
Number of Levels 1
Contact Tail Length 0.142 3.60mm
Termination Style Solder
Reach Compliance Code not_compliant
Insulation Height 0.748 19.00mm
Pitch 0.200 5.08mm
Color Green
Type Header, Female Sockets
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Explosion Proof, Mating and Mounting Flange, Retention Latches
Series COMBICON ICV
Published 2014
Packaging Bulk

Physical

Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 6 Weeks
