1805685
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pin strip (precision) PST Total number of pins 8 Phoenix Contact 1805685 Contact spacing: 5 mm 100 pc(s)
PDF
/
Inventory: 1077
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2014
Series COMBICON PST
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Partial Shroud
Number of Positions 8
Color Black
Pitch 0.197 5.00mm
Current Rating 12A
Termination Style Solder
Contact Tail Length 0.142 3.60mm
Number of Levels 1
Contact Mating Finish Tin
Voltage - IEC 600V
Header Orientation Vertical
Dimensions
Height 13mm
Length 2.8mm
Width 40mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
