1803293 image
Favorite
1803293 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description TERM BLOCK HDR 4POS 90DEG 3.81MM
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.0648
≥1 USD $1.0648
Inventory: 7674
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Width 18.7mm
Length 16.63mm
Height 7.4mm

Technical

Test Voltage 2.5kV
Fastening Method CONNECTOR
Header Orientation 90°, Right Angle
Safety Approval CB; CCA; CSA; CUL; EAC; UL
Number of Ways 4
Voltage - IEC 250V
Number of Decks 1
Number of Poles 4
Current 8A
Number of Levels 1
Max Current Rating 8A
Contact Tail Length 0.134 3.40mm
Voltage 300V
Contact Gender Male
Lead Pitch 3.81mm
Approval Agency CSA, UL
Voltage - Rated AC 160V
Termination Style Solder
Current Rating 8A
Insulation Height 0.285 7.25mm
Depth 9.2mm
Orientation Right Angle
Pitch 0.150 3.81mm
Voltage - Rated DC 640mV
Number of Rows 1
Color Green
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series COMBICON MC
Published 2003
Packaging Bulk

Physical

Weight 113.398093g
Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin

Supply Chain

Factory Lead Time 7 Weeks
