1796678
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block; header; 3 positions; 0.300" (7.62mm) pitch; Solder
PDF
/
Buying Options
Total Price: USD $3.95
Unit Price: USD $3.947164
≥1 USD $3.947164
≥10 USD $3.723741
≥100 USD $3.512966
≥500 USD $3.314115
≥1000 USD $3.126524
Inventory: 1124
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Header Orientation Vertical
Contact Mating Finish Tin
Current 12A
Number of Levels 1
Contact Tail Length 0.154 3.90mm
Voltage 400V
Termination Style Solder
Current Rating 12A
Reach Compliance Code not_compliant
Insulation Height 0.472 12.00mm
Pitch 0.300 7.62mm
Voltage - Rated 400V
Color Green
Number of Positions 3
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Explosion Proof, Mating and Mounting Flange
Series COMBICON GMSTBV
Published 2012
Packaging Bulk
Physical
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
