RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Pluggable Terminal Blocks 4 Pos 15mm pitch Feed Thru Invert Hdr
PDF
/
Inventory: 1117
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Positions Per Level 4
Current - IEC 125A
Header Orientation Vertical
Voltage - UL 600V
Current 115A
Number of Levels 1
Contact Tail Length 0.181 4.60mm
Voltage 600V
Termination Style Solder
Current Rating 125A
Reach Compliance Code not_compliant
Insulation Height 1.768 44.90mm
Pitch 0.591 15.00mm
Voltage - Rated 1kV
Color Green
Type Header, Blade Sockets
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating and Mounting Flange
Series COMBICON DFK-IPCV
Published 2012
Packaging Bulk

Physical

Housing Material Polybutylene Terephthalate (PBT)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Silver

Supply Chain

Factory Lead Time 7 Weeks
