1788716
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 20 Pos 5.08mm pitch Box Header
PDF
/
Buying Options
Total Price: USD $29.52
Unit Price: USD $29.5152
≥1 USD $29.5152
≥10 USD $28.71088
≥100 USD $26.833136
≥500 USD $24.686376
≥1000 USD $24.224218
Inventory: 68
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Cable
Mounting Type Board Mount
Material Polyamide
Housing Material Polyamide (PA), Nylon
Weight 206.999996g
Technical
Packaging Bulk
Published 2010
Series COMBICON MVSTBU
Feature Mounting Flange
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Type Receptacle, Male Pins
Color Green
Number of Rows 1
Gender Female
Voltage - Rated 320V
Additional Feature UL 94V-0, PA, SAFETY APPROVAL: UL; VDE
HTS Code 8536.69.40.40
Pitch 0.200 5.08mm
Orientation Straight
Depth 20.4mm
Insulation Height 0.681 17.30mm
Reach Compliance Code not_compliant
Current Rating 12A
Termination Style Screw
Approval Agency CB, CSA, UL, VDE
Voltage 300V
Number of Levels 1
Current 10A
Wire Gauge (Max) 12 AWG
Wire Gauge (Min) 24 AWG
Number of Decks 1
Wire Gauge or Range - AWG 12-30 AWG
Voltage - IEC 630V
Torque - Screw 0.5-0.6 Nm (4.4-5.3 Lb-In)
Number of Ways 20
Safety Approval CB; CCA; CSA; CUL; EAC
Wire Gauge or Range - mm2 0.2-2.5mm2
Current - IEC 12A
Number of Positions Per Level 20
Screw Size M3
Wire Cross Section 2.5 mm2
Dimensions
Height 20.4mm
Length 7mm
Width 17.3mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
