1786475
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Socket Strip SKT 9 POS 5.08mm Solder RA Thru-Hole
PDF
/
Buying Options
Total Price: USD $8.09
Unit Price: USD $8.0872
≥1 USD $8.0872
≥10 USD $7.86456
≥100 USD $7.34976
≥500 USD $6.761832
≥1000 USD $6.6352
Inventory: 646
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 47.72mm
Length 47.72mm
Height 10.35mm
Technical
Fastening Method CONNECTOR
Number of Positions Per Level 9
Header Orientation 90°, Right Angle
Safety Approval CB; CCA; CSA; CUL; EAC; UL
Number of Ways 9
Voltage - IEC 630V
Current - UL 10A
Number of Decks 1
Current 12A
Number of Levels 1
Max Current Rating 12A
Contact Tail Length 0.138 3.50mm
Voltage 300V
Termination Style Solder
Current Rating 12A
Insulation Height 0.402 10.20mm
Depth 19mm
Orientation Right Angle
Pitch 0.200 5.08mm
Voltage - Rated 320V
Number of Rows 1
Color Green
Type Header, Female Sockets
Connector Type Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Retention Latches
Series COMBICON IC
Published 2011
Packaging Bulk
Physical
Weight 164.000007g
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 4 Weeks
