1777112
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Shrouded Header (4 Sides) HDR 6 POS 5.08mm Solder ST Thru-Hole
PDF
/
Buying Options
Total Price: USD $3.73
Unit Price: USD $3.7312
≥1 USD $3.7312
≥10 USD $3.57192
≥100 USD $3.474592
≥500 USD $3.2472
≥1000 USD $2.987424
≥3000 USD $2.931491
Inventory: 431
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Copper
Mount Through Hole
Mounting Type Through Hole
Housing Material Polybutylene Terephthalate (PBT)
Weight 154.999997g
Technical
Packaging Bulk
Published 2010
Series COMBICON MSTBV
Feature Mating and Mounting Flange
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Type Header, Male Pins, Shrouded (4 Side)
Min Operating Temperature -40°C
Color Green
Number of Rows 1
Voltage - Rated 250V
Additional Feature PBT, UL 94V-0, SAFETY APPROVAL VDE
Pitch 0.200 5.08mm
Orientation Straight
Depth 8.3mm
Insulation Height 0.472 12.00mm
Reach Compliance Code not_compliant
Current Rating 12A
Termination Style Solder
Voltage 300V
Contact Tail Length 0.154 3.90mm
Max Current Rating 12A
Number of Levels 1
Current 12A
Contact Mating Finish Tin
Number of Decks 1
Voltage - IEC 630V
Number of Ways 6
Safety Approval CCA; CB; CSA; CUL; GL; GOST
Header Orientation Vertical
Number of Positions Per Level 6
Fastening Method CONNECTOR
Dimensions
Height 15.9mm
Length 40.64mm
Width 40.64mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
