1766013
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 2 Pos 7.5mm pitch Through Hole Header
PDF
/
Inventory: 9882
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Through Hole
Housing Material Polyamide (PA), Nylon
Technical
Packaging Bulk
Published 2011
Series COMBICON GMSTB
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Male Pins, Shrouded (2 Side)
Number of Positions 2
Color Green
Number of Rows 1
HTS Code 8536.69.40.40
Pitch 0.295 7.50mm
Insulation Height 0.339 8.61mm
Termination Style Solder
Contact Tail Length 0.138 3.50mm
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Number of Decks 1
Current - UL 15A
Voltage - IEC 630V
Number of Ways 2
Header Orientation 90°, Right Angle
Current - IEC 12A
Fastening Method PLUG IN
Rated Voltage 400V
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
