1756485
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 2 Pos 7.62mm pitch Thru Hole Invert Hdr
PDF
/
Buying Options
Total Price: USD $2.19
Unit Price: USD $2.189283
≥1 USD $2.189283
≥10 USD $2.065361
≥100 USD $1.948454
≥500 USD $1.83816
≥1000 USD $1.73411
Inventory: 7930
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Number of Positions Per Level 2
Header Orientation Vertical
Number of Ways 2
Voltage - IEC 1kV
Number of Decks 1
Voltage - UL 250V
Contact Mating Finish Tin
Current 16A
Number of Levels 1
Contact Tail Length 0.142 3.60mm
Voltage 250V
Termination Style Solder
Current Rating 16A
Insulation Height 0.748 19.00mm
Pitch 0.300 7.62mm
HTS Code 8536.69.40.40
Voltage - Rated 630V
Number of Rows 1
Color Green
Type Header, Female Sockets
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Retention Latches
Series COMBICON GICV
Published 2011
Packaging Bulk
Physical
Housing Material Polyamide (PA), Nylon
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
