1753446
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
COMBICON CCDN RoHS Compliant 2011 Mating Flange Terminal Block Header, Male Pins, Shrouded (4 Side) 90° Right Angle 10A 300V 0.791 20.09mm
PDF
/
Buying Options
Total Price: USD $47.61
Unit Price: USD $47.614944
≥1 USD $47.614944
≥200 USD $18.998976
≥500 USD $18.364845
≥1000 USD $18.051062
Inventory: 1118
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Housing Material Liquid Crystal Polymer (LCP)
Technical
Packaging Bulk
Published 2011
Series COMBICON CCDN
Feature Mating Flange
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 32
Color Black
Voltage - Rated 250V
Pitch 0.200 5.08mm
Insulation Height 0.791 20.09mm
Reach Compliance Code not_compliant
Current Rating 12A
Termination Style Solder
Voltage 300V
Contact Tail Length 0.102 2.60mm
Number of Levels 2
Current 10A
Contact Mating Finish Tin
Voltage - UL 300V
Voltage - IEC 400V
Header Orientation 90°, Right Angle
Current - IEC 12A
Number of Positions Per Level 16
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
