1751073
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK HDR 10POS 5.08MM
PDF
/
Buying Options
Total Price: USD $4.7
Unit Price: USD $4.6992
≥1 USD $4.6992
≥10 USD $4.56808
≥100 USD $4.26888
≥500 USD $3.927352
≥1000 USD $3.853837
Inventory: 108
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 5.880003g
Technical
Packaging Bulk
Published 2008
Series COMBICON MSTB
Feature Mating and Mounting Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 10
Color Black
Number of Rows 1
Gender Male
Voltage - Rated 250V
Additional Feature SAFETY APPROVAL: EAC
HTS Code 8536.69.40.40
Pitch 0.200 5.08mm
Insulation Height 0.339 8.61mm
Reach Compliance Code not_compliant
Current Rating 12A
Termination Style Solder
Voltage 300V
Contact Tail Length 0.138 3.50mm
Max Current Rating 12A
Number of Levels 1
Current 15A
Contact Mating Finish Tin
Number of Decks 1
Voltage - IEC 250V
Number of Ways 10
Safety Approval CB; CCA; CSA; CUL; UL; VDE
Header Orientation 90°, Right Angle
Number of Positions Per Level 10
Compliance
RoHS Status RoHS Compliant
