1749340
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK HDR 6POS 90DEG 3.81MM
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.256
≥1 USD $3.256
≥10 USD $3.16976
≥100 USD $2.96208
≥500 USD $2.725096
≥1000 USD $2.674109
Inventory: 135
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0
Technical
Header Orientation 90°, Right Angle
Positions Per Level 3
Voltage - IEC 250V
Contact Mating Finish Tin
Number of Levels 2
Contact Tail Length 0.055 1.40mm
Termination Style Solder
Current Rating 8A
Insulation Height 0.598 15.19mm
Pitch 0.150 3.81mm
Voltage - Rated 250V
Color Black
Number of Positions 6
Type Header, Male Pins, Shrouded (4 Side)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series COMBICON MCDN
Published 2014
Packaging Bulk
Physical
Housing Material Liquid Crystal Polymer (LCP)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 6 Weeks
