1748707
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Pluggable Terminal Blocks 2 Pos 10.16mm Invert Plug 18-4AWG Spring
PDF
/
Buying Options
Total Price: USD $12.65
Unit Price: USD $12.6456
≥1 USD $12.6456
≥10 USD $12.29712
≥100 USD $11.4928
≥500 USD $10.573464
≥1000 USD $9.768915
≥3000 USD $9.309256
Inventory: 86
Minimum: 1
-
+
Technical Details
Technical
Number of Decks 1
Wire Gauge or Range - AWG 4-20 AWG
Voltage - IEC 1kV
Number of Ways 2
Safety Approval UL
Plug Wire Entry 180°
Wire Gauge or Range - mm2 0.75-16mm2
Wire Strip Length 18mm
Current - IEC 76A
Number of Positions Per Level 2
Fastening Method SPRING LOADED
Contact Mating Finish Silver
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 4 AWG
Current 66A
Number of Levels 1
Voltage 600V
Termination Style Screwless - Push-In Spring
Current Rating 76A
Insulation Height 0.988 25.10mm
Pitch 0.400 10.16mm
HTS Code 8536.69.40.40
Additional Feature PA, UL 94V0
Voltage - Rated 1kV
Gender Female
Number of Rows 1
Color Green
Type Plug, Male Pins
ECCN Code EAR99
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating Flange
Series COMBICON ISPC
Published 2011
Packaging Bulk
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Physical
Weight 21.900007g
Housing Material Polyamide (PA), Nylon
Material Polyamide, Silver
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Supply Chain
Factory Lead Time 12 Weeks
