RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Phoenix Contact COMBICON FKCN Series 5mm Pitch Pluggable Terminal Block, Plug with Spring Cage Termination, 11 Way
PDF
/
Buying Options
Total Price: USD $10.11
Unit Price: USD $10.1112
≥1 USD $10.1112
Inventory: 143
Minimum: 1
-
+

Technical Details

Compliance

Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Material Flammability Rating UL94 V-0

Technical

Wire Strip Length 10mm
Wire Gauge or Range - mm2 0.2-1.5mm2
Plug Wire Entry 180°
Voltage - IEC 320V
Wire Gauge or Range - AWG 16-24 AWG
Contact Mating Finish Tin
Number of Levels 1
Termination Style Screwless - Leg Spring, Push-In Spring
Current Rating 12A
Insulation Height 0.429 10.90mm
Pitch 0.197 5.00mm
Voltage - Rated 630V
Gender Female
Color Green
Number of Positions 11
Type Plug, Female Sockets
Part Status Active
Series COMBICON FKCN
Published 2015
Packaging Bulk

Physical

Housing Material Polybutylene Terephthalate (PBT)
Material PBT, Tin
Mounting Type Free Hanging (In-Line)

Supply Chain

Factory Lead Time 8 Weeks
