39353-0010
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
TERM BLOCK HDR 10POS VERT 3.5MM
PDF
/
Inventory: 2200
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Technical
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 16 AWG
Current 10A
Voltage 300V
Insulation Resistance 5GOhm
Contact Resistance 1mOhm
UL Flammability Code 94V-0
Number of Contacts 10
Current Rating 10A
Reach Compliance Code unknown
Orientation Vertical
Pitch 3.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Voltage - Rated 300V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature 0°C
Max Operating Temperature 140°C
Connector Type BOARD CONNECTOR
Termination Solder
Part Status Discontinued
Published 2005
Physical
Housing Material Thermoplastic
Mount Through Hole
Contact Plating Gold
Contact Material Brass
