0399910311
RoHS
/
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Terminal Block F 11 POS 5mm Screw RA Cable Mount 10A/Contact
PDF
/
Inventory: 9633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 55.8mm
Technical
Screw Size M3
Number of Positions Per Level 11
Plug Wire Entry 90°
Positions Per Level 11
Current - UL 10A
Wire Gauge or Range - AWG 12-24 AWG
Voltage - UL 300V
Contact Mating Finish Gold
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 24 AWG
Current 10A
Number of Levels 1
Max Supply Voltage 300V
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.620 15.75mm
Depth 14.1mm
Orientation Right Angle
Pitch 0.197 5.00mm
Number of Rows 1
Color Black
Number of Positions 11
Type Plug for Unshrouded Header
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Locking Ramp
Series Eurostyle 39991
Packaging Bulk
Operating Temperature 110°C
Physical
Housing Material Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Gold, Tin
Contact Material Phosphor Bronze
