0399300214
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 28 POS 3.81mm Screw ST Cable Mount 12A/Contact
PDF
/
Inventory: 9972
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Physical
Contact Material Copper
Contact Plating Tin
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic
Technical
Operating Temperature -40°C~120°C
Packaging Bulk
Series EuroMate 39930
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Barrier Strip
Number of Positions 14
Max Operating Temperature 120°C
Min Operating Temperature -40°C
Color Black
Number of Rows 2
Pitch 0.150 3.81mm
Orientation Vertical
Depth 18.29mm
Insulation Height 1.005 25.53mm
Current Rating 12A
Termination Style Screw with Captive Plate
Number of Contacts 28
Housing Color Black
Voltage 300V
Number of Circuits 13
Number of Levels 1 (Mate), 2 (Input)
Current 12A
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 14 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 14-22 AWG
Current - UL 12A
Torque - Screw 0.79 Nm (7.0 Lb-In)
Positions Per Level 14 (Mate), 7 (Input)
Plug Wire Entry 90°
Screw Size M3
Max Supply Voltage (AC) 300V
Dimensions
Length 58.4mm
Compliance
RoHS Status ROHS3 Compliant
