0398600102

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description TERM BLOCK PLUG 2POS STR 5.08MM
PDF
/
Inventory: 6447
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Rated Voltage 300V
Screw Size M3
Plug Wire Entry 180°
Safety Approval UL; CSA
Number of Ways 2
Wire Gauge or Range - AWG 12-26 AWG
Number of Decks 1
Voltage - UL 300V
Contact Mating Finish Tin
Number of Levels 1
Lead Pitch 5.08mm
Termination Style Screw - Rising Cage Clamp
Current Rating 15A
Insulation Height 0.591 15.00mm
Orientation Horizontal
Pitch 0.200 5.08mm
HTS Code 8536.69.40.40
Additional Feature 94V-0
Number of Rows 1
Color Black
Number of Positions 2
Type Plug, Female Sockets
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Retention Latches (Non-Wire Side)
Series Eurostyle 39860
Packaging Bulk
Operating Temperature 110°C

Physical

Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Contact Material Phosphor Bronze
