0395345014

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Conn Eurostyle Block F 14 POS 5.08mm Screw RA Cable Mount 15A/Contact
PDF
/
Inventory: 8724
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Technical

Number of Positions Per Level 14
Wire Strip Length 6.5mm
Plug Wire Entry 180°
Positions Per Level 14
Torque - Screw 0.56 Nm (5.0 Lb-In)
Current - UL 18A
Wire Gauge or Range - AWG 12-30 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 30 AWG
Current 18A
Number of Levels 1
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Insulation Height 0.591 15.00mm
Pitch 0.200 5.08mm
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 115°C
Number of Positions 14
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mating Flange
Series Eurostyle ESE 39534
Packaging Bulk
Operating Temperature -40°C~115°C

Physical

Housing Material Polyamide (PA66), Nylon 6/6
Number of Pins 14
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Phosphor Bronze

Supply Chain

Factory Lead Time 12 Weeks
