0395333824
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 24 POS 5.08mm Screw ST Cable Mount 15A/Contact
PDF
/
Inventory: 7293
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Series Eurostyle ESE 39533
Feature Positions Stamped, Retention Latches (Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 24
Color Black
Pitch 0.200 5.08mm
Insulation Height 1.020 25.91mm
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Contact Mating Finish Gold
Voltage - UL 300V
Wire Gauge or Range - AWG 12-26 AWG
Current - UL 15A
Torque - Screw 0.56 Nm (5.0 Lb-In)
Plug Wire Entry 90°
Wire Strip Length 5mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
