0395300704
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 4 POS 5.08mm Screw RA Cable Mount 15A/Contact
PDF
/
Inventory: 8350
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 20.32mm
Technical
Screw Size M3
Wire Strip Length 5mm
Plug Wire Entry 180°
Torque - Screw 0.56 Nm (5.0 Lb-In)
Wire Gauge or Range - AWG 12-26 AWG
Contact Mating Finish Gold
Wire Gauge (Min) 12 AWG
Wire Gauge (Max) 26 AWG
Current 15A
Number of Levels 1
Max Supply Voltage 300V
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Reach Compliance Code unknown
Insulation Height 0.591 15.00mm
Depth 18.2mm
Orientation Right Angle
Pitch 0.200 5.08mm
Color Black
Number of Positions 4
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Positions Stamped, Retention Latches (Non-Wire Side)
Series Eurostyle ESE 39530
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Polyamide (PA), Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 12 Weeks
