0395200105

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Conn Eurostyle Block F 5 POS 5mm Screw RA Cable Mount 15A/Contact Eurostyle?
PDF
/
Buying Options
Total Price: USD $2.4
Unit Price: USD $2.4024
≥1 USD $2.4024
≥10 USD $1.8304
≥100 USD $1.714592
≥500 USD $1.52416
≥1000 USD $1.491072
≥3000 USD $1.458371
Inventory: 1138
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Contact Material Phosphor Bronze
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6

Technical

Operating Temperature -40°C~115°C
Packaging Bulk
Series Eurostyle ESE 39520
Feature Positions Stamped, Retention Latches (Non-Wire Side)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Plug, Female Sockets
Number of Positions 5
Color Black
Pitch 0.197 5.00mm
Insulation Height 0.591 15.00mm
Termination Style Screw - Rising Cage Clamp
Number of Levels 1
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 12-30 AWG
Current - UL 18A
Torque - Screw 0.56 Nm (5.0 Lb-In)
Plug Wire Entry 180°
Wire Strip Length 6.5mm

Compliance

Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
