0395178903
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 3 POS 3.81mm Screw ST Cable Mount 8A/Contact
PDF
/
Inventory: 6913
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Technical
Wire Strip Length 6.5mm
Plug Wire Entry 90°
Torque - Screw 0.23 Nm (2.0 Lb-In)
Wire Gauge or Range - AWG 16-30 AWG
Contact Mating Finish Gold
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 30 AWG
Current 8A
Number of Levels 1
Voltage 300V
Termination Style Screw - Rising Cage Clamp
Reach Compliance Code unknown
Insulation Height 0.740 18.80mm
Pitch 0.150 3.81mm
Color Green
Number of Positions 3
Type Plug, Female Sockets
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Mating Flange, Positions Stamped
Series Eurostyle ESE 39517
Packaging Bulk
Operating Temperature -40°C~115°C
Physical
Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 12 Weeks
