0395172420
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 20 POS 3.81mm Screw ST Cable Mount 8A/Contact
PDF
/
Inventory: 9268
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Number of Pins 20
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series Eurostyle ESE 39517
Feature Mating Flange, Positions Stamped
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 20
Max Operating Temperature 115°C
Min Operating Temperature -40°C
Color Black
Pitch 0.150 3.81mm
Insulation Height 0.740 18.80mm
Termination Style Screw - Rising Cage Clamp
Voltage 300V
Number of Levels 1
Current 8A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-30 AWG
Current - UL 8A
Torque - Screw 0.23 Nm (2.0 Lb-In)
Positions Per Level 20
Plug Wire Entry 270°
Wire Strip Length 6.5mm
Number of Positions Per Level 20
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
