0395105706
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 6 POS 3.81mm Screw RA Cable Mount 8A/Contact
PDF
/
Inventory: 5630
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Gold
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series Eurostyle ESE 39510
Feature Positions Stamped
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 6
Max Operating Temperature 115°C
Min Operating Temperature -40°C
Color Green
Number of Rows 1
Pitch 0.150 3.81mm
Orientation Right Angle
Insulation Height 0.437 11.10mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 6
Housing Color Green
Voltage 300V
Number of Levels 1
Current 8A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Gold
Voltage - UL 300V
Wire Gauge or Range - AWG 16-30 AWG
Current - UL 8A
Torque - Screw 0.23 Nm (2.0 Lb-In)
Positions Per Level 6
Plug Wire Entry 180°
Wire Strip Length 6.5mm
Number of Positions Per Level 6
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
