0395040507
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Conn Eurostyle Block F 7 POS 3.5mm Screw RA Cable Mount 8A/Contact
PDF
/
Inventory: 9133
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Phosphor Bronze
Contact Plating Gold
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -40°C~115°C
Packaging Bulk
Series Eurostyle ESE 39504
Feature Mating Flange
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screw
Type Plug, Female Sockets
Number of Positions 7
Max Operating Temperature 115°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Pitch 0.138 3.50mm
Orientation Right Angle
Insulation Height 0.437 11.10mm
Termination Style Screw - Rising Cage Clamp
Number of Contacts 7
Housing Color Black
Voltage 300V
Number of Levels 1
Current 8A
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Gold
Voltage - UL 300V
Wire Gauge or Range - AWG 16-30 AWG
Current - UL 8A
Torque - Screw 0.23 Nm (2.0 Lb-In)
Positions Per Level 7
Plug Wire Entry 180°
Wire Strip Length 6.5mm
Number of Positions Per Level 7
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
