EM257504HC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Plug
PDF
/
Buying Options
Total Price: USD $1.13
Unit Price: USD $1.134182
≥1 USD $1.134182
≥10 USD $1.069981
≥100 USD $1.009413
≥500 USD $0.95228
≥1000 USD $0.898382
Inventory: 1081
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material Brass
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Weight 907.18474mg
Technical
Operating Temperature -40°C~105°C
Packaging Bulk
Published 2009
Series Euro-Mag EM2575
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Header, Male Pins, Shrouded (4 Side)
Number of Positions 4
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Green
Voltage - Rated 300V
Pitch 0.200 5.08mm
Insulation Height 0.327 8.30mm
Current Rating 16A
Termination Style Solder
Number of Contacts 4
Voltage 300V
Contact Tail Length 0.177 4.50mm
Number of Levels 1
Current 16A
Contact Mating Finish Tin
Voltage - UL 300V
Current - UL 16A
Positions Per Level 4
Header Orientation 90°, Right Angle
Number of Positions Per Level 4
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
