SCVF12400
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description
Terminal Block Socket
PDF
/
Inventory: 924
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Copper Alloy
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature 105°C
Packaging Tray
Published 2006
Series SCVF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Screwless
Type Plug, Female Sockets
Number of Positions 12
Color Black
Number of Rows 1
Gender Female
Pitch 0.150 3.81mm
Orientation Straight
Insulation Height 0.480 12.20mm
Termination Style Screwless - Spring Cage, Tension Clamp
Number of Contacts 12
Housing Color Black
Voltage 300V
Number of Circuits 12
Number of Levels 1
Current 12A
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 16 AWG
Contact Mating Finish Tin
Voltage - UL 300V
Wire Gauge or Range - AWG 16-28 AWG
Current - UL 12A
Positions Per Level 12
Plug Wire Entry 180°
Wire Strip Length 8.38mm
Number of Positions Per Level 12
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant
