SCVF03400

Amphenol PCD
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Terminal Blocks - Headers, Plugs and Sockets
Description Terminal Block Socket
PDF
/
Buying Options
Total Price: USD $4.07
Unit Price: USD $4.0744
≥1 USD $4.0744
≥10 USD $3.10376
≥100 USD $2.906816
≥500 USD $2.5839
≥1000 USD $2.527712
Inventory: 243
Minimum: 1
-
+

Technical Details

Technical

Positions Per Level 3
Plug Wire Entry 180°
Wire Strip Length 8.38mm
Number of Positions Per Level 3
Current - UL 12A
Wire Gauge or Range - AWG 16-28 AWG
Voltage - UL 300V
Contact Mating Finish Tin
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 28 AWG
Current 12A
Number of Levels 1
Number of Circuits 3
Voltage 300V
Housing Color Black
Number of Contacts 3
Termination Style Screwless - Spring Cage, Tension Clamp
Insulation Height 0.480 12.20mm
Orientation Straight
Pitch 0.150 3.81mm
Gender Female
Number of Rows 1
Color Black
Number of Positions 3
Type Plug, Female Sockets
Termination Screwless
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SCVF
Published 2006
Packaging Tray
Operating Temperature 105°C

Compliance

Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status RoHS Compliant

Physical

Housing Material Polyamide (PA66), Nylon 6/6
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Copper Alloy

Supply Chain

Factory Lead Time 8 Weeks
